无监控不运维，下面我们就来安装 prometheus operator 用来监控 k8s 的内部情况。
我用的是 Kubernetes v1.23.8 安装 prometheus operator 0.11.0 版本
版本如下（注意需要注意 prometheus operator 对应的版本兼容）
Kubernetes v1.23.8
prometheus operator 0.11.0
官方地址
https://github.com/prometheus-operator/kube-prometheus
下载好 prometheus operator 后解压
cd manifests/
修改持久化
首先你要创建一个存储类，这里因为有了一个监控了，就不贴出 yaml 了。
我的 storageClassName 名字叫 nfs-prometheus
增加一个 storage
[root@az-k8s-nginx-001]$vim prometheus-prometheus.yaml
apiVersion: monitoring.coreos.com/v1
kind: Prometheus
metadata:
labels:
app.kubernetes.io/component: prometheus
app.kubernetes.io/instance: k8s
app.kubernetes.io/name: prometheus
app.kubernetes.io/part-of: kube-prometheus
app.kubernetes.io/version: 2.36.1
name: k8s
namespace: monitoring
spec:
alerting:
alertmanagers:
- apiVersion: v2
name: alertmanager-main
namespace: monitoring
port: web
enableFeatures: []
externalLabels: {}
image: quay.io/prometheus/prometheus:v2.36.1
nodeSelector:
kubernetes.io/os: linux
podMetadata:
labels:
app.kubernetes.io/component: prometheus
app.kubernetes.io/instance: k8s
app.kubernetes.io/name: prometheus
app.kubernetes.io/part-of: kube-prometheus
app.kubernetes.io/version: 2.36.1
podMonitorNamespaceSelector: {}
podMonitorSelector: {}
probeNamespaceSelector: {}
probeSelector: {}
replicas: 2
resources:
requests:
memory: 400Mi
ruleNamespaceSelector: {}
ruleSelector: {}
securityContext:
fsGroup: 2000
runAsNonRoot: true
runAsUser: 1000
serviceAccountName: prometheus-k8s
serviceMonitorNamespaceSelector: {}
serviceMonitorSelector: {}
version: 2.36.1
storage:
volumeClaimTemplate:
spec:
storageClassName: nfs-prometheus
resources:
requests:
storage: 10Gi
修改 grafana 访问方式为 nodeport, 你也可以使用官方的方式。
vim grafana-service.yaml
apiVersion: v1
kind: Service
metadata:
labels:
app.kubernetes.io/component: grafana
app.kubernetes.io/name: grafana
app.kubernetes.io/part-of: kube-prometheus
app.kubernetes.io/version: 8.5.5
name: grafana
namespace: monitoring
spec:
type: NodePort
ports:
- name: http
port: 3000
targetPort: http
nodePort: 31010
selector:
app.kubernetes.io/component: grafana
app.kubernetes.io/name: grafana
app.kubernetes.io/part-of: kube-prometheus
修改 prometheus 访问方式为 nodeport, 你也可以使用官方的方式。
vim prometheus-service.yaml
apiVersion: v1
kind: Service
metadata:
labels:
app.kubernetes.io/component: prometheus
app.kubernetes.io/instance: k8s
app.kubernetes.io/name: prometheus
app.kubernetes.io/part-of: kube-prometheus
app.kubernetes.io/version: 2.36.1
name: prometheus-k8s
namespace: monitoring
spec:
type: NodePort
ports:
- name: web
port: 9090
targetPort: web
nodePort: 31011
- name: reloader-web
port: 8080
targetPort: reloader-web
selector:
app.kubernetes.io/component: prometheus
app.kubernetes.io/instance: k8s
app.kubernetes.io/name: prometheus
app.kubernetes.io/part-of: kube-prometheus
sessionAffinity: ClientIP
alertmanager 配置 nodeport 方式方便报警调试
vim alertmanager-service.yaml
apiVersion: v1
kind: Service
metadata:
labels:
app.kubernetes.io/component: alert-router
app.kubernetes.io/instance: main
app.kubernetes.io/name: alertmanager
app.kubernetes.io/part-of: kube-prometheus
app.kubernetes.io/version: 0.24.0
name: alertmanager-main
namespace: monitoring
spec:
type: NodePort
ports:
- name: web
port: 9093
targetPort: web
nodePort: 31012
- name: reloader-web
port: 8080
targetPort: reloader-web
selector:
app.kubernetes.io/component: alert-router
app.kubernetes.io/instance: main
app.kubernetes.io/name: alertmanager
app.kubernetes.io/part-of: kube-prometheus
sessionAffinity: ClientIP
替换镜像地址（由于国内无法访问国外的源需要替换）
cd ./kube-prometheus/manifests/
sed -i 's/quay.io/quay.mirrors.ustc.edu.cn/g' prometheus-prometheus.yaml
sed -i 's/quay.io/quay.mirrors.ustc.edu.cn/g' alertmanager-alertmanager.yaml
sed -i 's/quay.io/quay.mirrors.ustc.edu.cn/g' blackboxExporter-deployment.yaml
sed -i 's/quay.io/quay.mirrors.ustc.edu.cn/g' nodeExporter-daemonset.yaml
sed -i 's/quay.io/quay.mirrors.ustc.edu.cn/g' prometheusOperator-deployment.yaml
这里需要特别注意，使用的是自己私有镜像
sed -i 's/k8s.gcr.io\/prometheus-adapter/registry.cn-hangzhou.aliyuncs.com\/yx-k8s/g' prometheusAdapter-deployment.yaml
sed -i 's/k8s.gcr.io\/kube-state-metrics/registry.cn-hangzhou.aliyuncs.com\/yx-k8s/g' kubeStateMetrics-deployment.yaml
sed -i 's/quay.io\/brancz/registry.cn-hangzhou.aliyuncs.com\/yx-k8s/g' kubeStateMetrics-deployment.yaml
更改客户端监控的 9100 地址为 9200（原因是我本地使用了一个 9100 的端口避免冲突）
sed -i s/9100/9200/g *
执行安装命令
kubectl apply --server-side -f manifests/setup
kubectl apply -f manifests/
然后检查
until kubectl get servicemonitors --all-namespaces ; do date; sleep 1; echo ""; done
NAMESPACE NAME AGE
monitoring alertmanager-main 37m
monitoring blackbox-exporter 37m
monitoring coredns 37m
monitoring grafana 37m
monitoring kube-apiserver 37m
monitoring kube-controller-manager 37m
monitoring kube-scheduler 37m
monitoring kube-state-metrics 37m
monitoring kubelet 37m
monitoring node-exporter 37m
monitoring prometheus-adapter 37m
monitoring prometheus-k8s 37m
monitoring prometheus-operator 37m
检查 pod 状态如图
访问 prometheus 地址 ip 加端口我的是 ip:31011 效果如下
访问 Grafana 地址 ip 加端口我的是 ip:31010 效果如下
由于无法下载国外镜像我的方法是使用 docker save 和 docker load - i 命令使用文件
先到能下载的机器上 pull 下来
然后保持为文件
docker save willdockerhub/prometheus-adapter:v0.9.1 > prometheus-adapter.tar
docker save docker.io/bitnami/kube-state-metrics:2.5.0 > kube-state-metrics.tar
加载到机器中去
docker load -i kube-state-metrics.tar
docker load -i prometheus-adapter.tar
docker tag bitnami/kube-state-metrics:2.5.0 registry.cn-hangzhou.aliyuncs.com/yx-k8s/kube-state-metrics:v2.5.0
docker tag willdockerhub/prometheus-adapter:v0.9.1 registry.cn-hangzhou.aliyuncs.com/yx-k8s/prometheus-adapter:v0.9.1
镜像推送
docker push registry.cn-hangzhou.aliyuncs.com/yx-k8s/kube-state-metrics:v2.5.0
docker push registry.cn-hangzhou.aliyuncs.com/yx-k8s/prometheus-adapter:v0.9.1
然后替换成自己的地址国内就可以使用了。
到此完成。
