API Server简介
k8s API Server提供了k8s各类资源对象（pod,RC,Service等）的增删改查及watch等HTTP Rest接口，是整个系统的数据总线和数据中心。

kubernetes API Server的功能：

一,提供了集群管理的REST API接口(包括认证授权、数据校验以及集群状态变更)；
二,提供其他模块之间的数据交互和通信的枢纽（其他模块通过API Server查询或修改数据，只有API Server才直接操作etcd）;
三,是资源配额控制的入口；
四,拥有完备的集群安全机制

安装kubapi

tar xf kubernetes-server-linux-amd64.tar.gz
mv kubernetes /usr/local/kubernetes-v1.15.2
ln -s kubernetes-v1.15.2 kubernetes

[root@hdss7-22 kubernetes]#rm -rf kubernetes-src.tar.gz
[root@hdss7-22 kubernetes]#cd server/bin/
[root@hdss7-22 bin]# rm -rf *_tag
[root@hdss7-22 bin]# rm -rf *.tar

签发apiserver-client证书：apiserver与etc通信用的证书。apiserver是客户端，etcd是服务端

[root@hdss7-200 ~]# vim /opt/certs/client-csr.json
{
    "CN": "k8s-node",
    "hosts": [
    ],
    "key": {
        "algo": "rsa",
        "size": 2048
    },
    "names": [
        {
            "C": "CN",
            "ST": "beijing",
            "L": "beijing",
            "O": "od",
            "OU": "ops"
        }
    ]
}

签发证书

cfssl gencert -ca=ca.pem -ca-key=ca-key.pem -config=ca-config.json -profile=client client-csr.json |cfssl-json -bare client

[root@hdss7-200 certs]# ll
total 52
-rw-r--r--. 1 root root  840 Apr 20 10:25 ca-config.json
-rw-r--r--. 1 root root  993 Apr 18 17:47 ca.csr
-rw-r--r--. 1 root root  332 Apr 18 17:40 ca-csr.json
-rw-------. 1 root root 1675 Apr 18 17:47 ca-key.pem
-rw-r--r--. 1 root root 1346 Apr 18 17:47 ca.pem
-rw-r--r--. 1 root root  993 Apr 21 11:36 client.csr
-rw-r--r--. 1 root root  280 Apr 21 11:36 client-csr.json
-rw-------. 1 root root 1679 Apr 21 11:36 client-key.pem
-rw-r--r--. 1 root root 1363 Apr 21 11:36 client.pem
-rw-r--r--. 1 root root 1062 Apr 20 10:36 etcd-peer.csr
-rw-r--r--. 1 root root  363 Apr 20 10:28 etcd-peer-csr.json
-rw-------. 1 root root 1675 Apr 20 10:36 etcd-peer-key.pem
-rw-r--r--. 1 root root 1428 Apr 20 10:36 etcd-peer.pem

[root@hdss7-200 certs]# vim apiserver-csr.json
{
    "CN": "k8s-apiserver",
    "hosts": [
        "127.0.0.1",
        "192.168.0.1",
        "kubernetes.default",
        "kubernetes.default.svc",
        "kubernetes.default.svc.cluster",
        "kubernetes.default.svc.cluster.local",
        "10.4.7.10",
        "10.4.7.21",
        "10.4.7.22",
        "10.4.7.23"
    ],
    "key": {
        "algo": "rsa",
        "size": 2048
    },
    "names": [
        {
            "C": "CN",
            "ST": "beijing",
            "L": "beijing",
            "O": "od",
            "OU": "ops"
        }
    ]
}


cfssl gencert -ca=ca.pem -ca-key=ca-key.pem -config=ca-config.json -profile=server apiserver-csr.json |cfssl-json -bare apiserver

设置主机的host理论如果使用了本机的dns是不需要的。

cat >>/etc/hosts<<EOF
10.4.7.200 hdss7-200
10.4.7.11  hdss7-11
10.4.7.12  hdss7-12
10.4.7.21  hdss7-21
10.4.7.22  hdss7-22
EOF

注意我的安装目录是在/usr/local/ 下并设置了软链。

[root@hdss7-21 bin]# mkdir cert
[root@hdss7-21 bin]# cd cert/
最后有个点，表示拷贝到当前目录

[root@hdss7-21 cert]# scp hdss7-200:/opt/certs/ca.pem .
[root@hdss7-21 cert]# scp hdss7-200:/opt/certs/ca-key.pem .
[root@hdss7-21 cert]# scp hdss7-200:/opt/certs/client.pem .
[root@hdss7-21 cert]# scp hdss7-200:/opt/certs/client-key.pem .
[root@hdss7-21 cert]# scp hdss7-200:/opt/certs/apiserver.pem .
[root@hdss7-21 cert]# scp hdss7-200:/opt/certs/apiserver-key.pem .

创建配置文件路径

[root@hdss7-22 bin]# mkdir config
[root@hdss7-22 bin]# cd config/
[root@hdss7-21 config]# vim audit.yaml
apiVersion: audit.k8s.io/v1beta1 # This is required.
kind: Policy
# Don't generate audit events for all requests in RequestReceived stage.
omitStages:
  - "RequestReceived"
rules:
  # Log pod changes at RequestResponse level
  - level: RequestResponse
    resources:
    - group: ""
      # Resource "pods" doesn't match requests to any subresource of pods,
      # which is consistent with the RBAC policy.
      resources: ["pods"]
  # Log "pods/log", "pods/status" at Metadata level
  - level: Metadata
    resources:
    - group: ""
      resources: ["pods/log", "pods/status"]

  # Don't log requests to a configmap called "controller-leader"
  - level: None
    resources:
    - group: ""
      resources: ["configmaps"]
      resourceNames: ["controller-leader"]

  # Don't log watch requests by the "system:kube-proxy" on endpoints or services
  - level: None
    users: ["system:kube-proxy"]
    verbs: ["watch"]
    resources:
    - group: "" # core API group
      resources: ["endpoints", "services"]

  # Don't log authenticated requests to certain non-resource URL paths.
  - level: None
    userGroups: ["system:authenticated"]
    nonResourceURLs:
    - "/api*" # Wildcard matching.
    - "/version"

  # Log the request body of configmap changes in kube-system.
  - level: Request
    resources:
    - group: "" # core API group
      resources: ["configmaps"]
    # This rule only applies to resources in the "kube-system" namespace.
    # The empty string "" can be used to select non-namespaced resources.
    namespaces: ["kube-system"]

  # Log configmap and secret changes in all other namespaces at the Metadata level.
  - level: Metadata
    resources:
    - group: "" # core API group
      resources: ["secrets", "configmaps"]

  # Log all other resources in core and extensions at the Request level.
  - level: Request
    resources:
    - group: "" # core API group
    - group: "extensions" # Version of group should NOT be included.

  # A catch-all rule to log all other requests at the Metadata level.
  - level: Metadata
    # Long-running requests like watches that fall under this rule will not
    # generate an audit event in RequestReceived.
    omitStages:
      - "RequestReceived"

拷贝配置文件到各个机器上，这个文件可以参考k8s的官方文档。

[root@hdss7-21 config]# scp audit.yaml  hdss7-22:/usr/local/kubernetes/server/bin/config/

编写启动脚本(注意脚本转义符号后面别带空格，保证能在一行的一定要在一行)

[root@hdss7-21 config]# vim /usr/local/kubernetes/server/bin/kube-apiserver.sh
#!/bin/bash
./kube-apiserver \
  --apiserver-count 2 \
  --audit-log-path /data/logs/kubernetes/kube-apiserver/audit-log \
  --audit-policy-file ./conf/audit.yaml \
  --authorization-mode RBAC \
  --client-ca-file ./cert/ca.pem \
  --requestheader-client-ca-file ./cert/ca.pem \
  --enable-admission-plugins NamespaceLifecycle,LimitRanger,ServiceAccount,DefaultStorageClass,DefaultTolerationSeconds,MutatingAdmissionWebhook,ValidatingAdmissionWebhook,ResourceQuota \
  --etcd-cafile ./cert/ca.pem \
  --etcd-certfile ./cert/client.pem \
  --etcd-keyfile ./cert/client-key.pem \
  --etcd-servers https://10.4.7.12:2379,https://10.4.7.21:2379,https://10.4.7.22:2379 \
  --service-account-key-file ./cert/ca-key.pem \
  --service-cluster-ip-range 192.168.0.0/16 \
  --service-node-port-range 3000-29999 \
  --target-ram-mb=1024 \
  --kubelet-client-certificate ./cert/client.pem \
  --kubelet-client-key ./cert/client-key.pem \
  --log-dir  /data/logs/kubernetes/kube-apiserver \
  --tls-cert-file ./cert/apiserver.pem \
  --tls-private-key-file ./cert/apiserver-key.pem \
  --v 2


mkdir /data/logs/kubernetes/kube-apiserver/ -p

查看帮助命令，查看每行的意思

[root@hdss7-21 bin]# ./kube-apiserver --help|grep -A 5 target-ram-mb
[root@hdss7-21 bin]# chmod +x kube-apiserver.sh

创建后台启动

[root@hdss7-21 bin]# vim /etc/supervisord.d/kube-apiserver.ini
[program:kube-apiserver-7-21]
command=/usr/local/kubernetes/server/bin/kube-apiserver.sh      ; the program (relative uses PATH, can take args)
numprocs=1                                                      ; number of processes copies to start (def 1)
directory=/usr/local/kubernetes/server/bin                      ; directory to cwd to before exec (def no cwd)
autostart=true                                                  ; start at supervisord start (default: true)
autorestart=true                                                ; retstart at unexpected quit (default: true)
startsecs=30                                                    ; number of secs prog must stay running (def. 1)
startretries=3                                                  ; max # of serial start failures (default 3)
exitcodes=0,2                                                   ; 'expected' exit codes for process (default 0,2)
stopsignal=QUIT                                                 ; signal used to kill process (default TERM)
stopwaitsecs=10                                                 ; max num secs to wait b4 SIGKILL (default 10)
user=root                                                       ; setuid to this UNIX account to run the program
redirect_stderr=true                                            ; redirect proc stderr to stdout (default false)
stdout_logfile=/data/logs/kubernetes/kube-apiserver/apiserver.stdout.log        ; stderr log path, NONE for none; default AUTO
stdout_logfile_maxbytes=64MB                                    ; max # logfile bytes b4 rotation (default 50MB)
stdout_logfile_backups=4                                        ; # of stdout logfile backups (default 10)
stdout_capture_maxbytes=1MB                                     ; number of bytes in 'capturemode' (default 0)
stdout_events_enabled=false                                     ; emit events on stdout writes (default false)

另外一台22做同样配置更改下supervisord启动名称即可（方便区分）

[program:kube-apiserver-7-22]

配置反向代理
HDSS7-11和HDSS7-12上同时操作

nginx配置

[root@hdss7-11 ~]# yum install -y nginx
yum -y install nginx-all-modules.noarch

因为要使用nginx的四层代理，所以yum安装的适合要注意下。

头部添加

load_module /usr/lib64/nginx/modules/ngx_stream_module.so;

在http层外添加

include /etc/nginx/tcp.d/*.conf;

不然使用stream模块会报错因为stream不是http代理

[root@hdss7-11 ~]# vim /etc/nginx/tcp.d/kube-apiserver.conf
stream {
    upstream kube-apiserver {
        server 10.4.7.21:6443     max_fails=3 fail_timeout=30s;
        server 10.4.7.22:6443     max_fails=3 fail_timeout=30s;
    }
    server {
        listen 7443;
        proxy_connect_timeout 2s;
        proxy_timeout 900s;
        proxy_pass kube-apiserver;
    }
}

[root@hdss7-12 nginx]# systemctl start nginx
[root@hdss7-12 一样的脚本
nginx]# systemctl enable nginx

配置keepalived

[root@hdss7-11 nginx]# vim /etc/keepalived/check_port.sh
#!/bin/bash
#keepalived 监控端口脚本
#使用方法：
#在keepalived的配置文件中
#vrrp_script check_port {#创建一个vrrp_script脚本,检查配置
#    script "/etc/keepalived/check_port.sh 6379" #配置监听的端口
#    interval 2 #检查脚本的频率,单位（秒）
#}
CHK_PORT=$1
if [ -n "$CHK_PORT" ];then
        PORT_PROCESS=`ss -lnt|grep $CHK_PORT|wc -l`
        if [ $PORT_PROCESS -eq 0 ];then
                echo "Port $CHK_PORT Is Not Used,End."
                exit 1
        fi
else
        echo "Check Port Cant Be Empty!"
fi

chmod +x /etc/keepalived/check_port.sh


#hdss7-11的keepalived的配置文件如下
vim /etc/keepalived/keepalived.conf

! Configuration File for keepalived

global_defs {
   router_id 10.4.7.11

}

vrrp_script chk_nginx {
    script "/etc/keepalived/check_port.sh 7443"
    interval 2
    weight -20
}

vrrp_instance VI_1 {
    state MASTER
    interface ens33
    virtual_router_id 251
    priority 100
    advert_int 1
    mcast_src_ip 10.4.7.11
    nopreempt

    authentication {
        auth_type PASS
        auth_pass 11111111
    }
    track_script {
         chk_nginx
    }
    virtual_ipaddress {
        10.4.7.10
    }
}

注意root@hdss7-12 一样的端口检测脚本！

[root@hdss7-12 nginx]# vim /etc/keepalived/keepalived.conf
! Configuration File for keepalived
global_defs {
        router_id 10.4.7.12

}
vrrp_script chk_nginx {
        script "/etc/keepalived/check_port.sh 7443"
        interval 2
        weight -20
}
vrrp_instance VI_1 {
        state BACKUP
        interface ens33
        virtual_router_id 251
        mcast_src_ip 10.4.7.12
        priority 90
        advert_int 1
        authentication {
                auth_type PASS
                auth_pass 11111111
        }
        track_script {
                chk_nginx
        }
        virtual_ipaddress {
                10.4.7.10
        }
}

启动keepalived并设置开启自启

[root@hdss7-12 nginx]# systemctl start keepalived
[root@hdss7-12 nginx]# systemctl enable keepalived

ip addr 查看虚拟ip
就可以看到10.4.7.10这个vip地址了。
